OOP (Object-Oriented Programming) — Programmer’s Picnic (Champak Roy)

1) Your OOP storyboards (images)

Each image becomes a “chapter” of OOP understanding.

Champ Car Co. is founded — car class components and sub-components — **Image 1:** Car as a **class** made from **components** (composition).

Champ Bank plans its blueprint — BankAccount with components and methods — **Image 2:** BankAccount as a **class** with fields + methods (**deposit()**, **withdraw()**).

All components made fitted into final product — constructor in OOP — **Image 3:** Assembly time = **constructor** (sub-components → components → final object).

Constructor for BankAccount coded and called — **Image 4:** Constructor code in action: object created, parts fitted, ready to use.

Driver presses brake and pressure transmitted to wheels — **Image 5:** One action triggers internal work: method call → internal components respond.

Deposit and withdraw actions as UI buttons — **Image 6:** Two objects/users calling methods: **deposit** and **withdraw**.

Coming up next encapsulation polymorphism abstraction — **Image 7:** What’s next in OOP: **Encapsulation**, **Polymorphism**, **Abstraction**…

2) Big picture: OOP in one line

OOP = write programs by modeling real things as objects that have data (fields) + actions (methods).

Car & BankAccount mapping (from your images)

Car (object)
Data: body, engine, wheels, brakes…
Actions: start(), brake(), honk(), accelerate()

BankAccount (object)
Data: accountNo, customer, balance
Actions: deposit(), withdraw(), showBalance()

In your comics, the team first makes a blueprint (class), then breaks it into parts (composition), then assembles (constructor), then uses it by pressing buttons (methods).

3) Class vs Object (super clear)

Class = design / blueprint (like “Car (class)” or “BankAccount (class)”).
Object = real instance created from the class.
Many objects can come from one class (many accounts, many cars).

Quick memory:
Class = recipe • Object = cooked dish

Constructor (from Image 3 & 4)

Constructor runs when an object is created.
Its job: fit parts together and set starting values.
Python: __init__ • Java: ClassName(...) • JS: constructor(...)

4) Core OOP concepts (with simple examples)

Learn the “why”, not just the definitions.

Encapsulation
Keep data protected; allow access only through methods.
Example: balance should not be directly changed; use deposit()/withdraw().

Abstraction
Show only what user needs; hide internal complexity.
Example: “Press brake” — user doesn’t care about oil pressure, pads, discs details.

Inheritance
Reuse and extend: “child” class gets parent features.
Example: SavingsAccount and CurrentAccount share base Account rules.

Polymorphism
Same method name, different behavior depending on object type.
Example: payFee() works differently for Savings vs Current.

Composition (your Car example!)
A car has an engine, wheels, brakes… → “has-a” relationship. This keeps designs clean and real-world.

5) Code examples (Python / Java / JavaScript)

Same idea in 3 languages: BankAccount + composition + safe balance.

✅ OOP: class, object, constructor, encapsulation, composition

# Programmer's Picnic — OOP in Python (Champak Roy)
# Focus: composition + encapsulation + constructor

class Customer:
    def __init__(self, name, age, address, phone):
        self.name = name
        self.age = age
        self.address = address
        self.phone = phone

    def __repr__(self):
        return f"Customer(name={self.name!r}, age={self.age}, phone={self.phone!r})"


class Money:
    # A tiny helper class to show composition (BankAccount HAS-A Money)
    def __init__(self, rupees=0, paise=0):
        total = rupees * 100 + paise
        if total < 0:
            raise ValueError("Money can't be negative at creation.")
        self._paise = total  # internal storage in paise

    @property
    def paise(self):
        return self._paise

    def add(self, rupees=0, paise=0):
        self._paise += rupees * 100 + paise

    def can_subtract(self, rupees=0, paise=0):
        return self._paise - (rupees * 100 + paise) >= 0

    def subtract(self, rupees=0, paise=0):
        amount = rupees * 100 + paise
        if self._paise - amount < 0:
            raise ValueError("Insufficient balance.")
        self._paise -= amount

    def __repr__(self):
        r = self._paise // 100
        p = self._paise % 100
        return f"₹{r}.{p:02d}"


class BankAccount:
    # Encapsulation idea: balance is internal, only changed by methods
    def __init__(self, account_no, customer, opening_balance):
        # Constructor = assembly: fit parts into the final object
        self.account_no = account_no
        self.customer = customer          # composition
        self._balance = opening_balance   # keep it "private-ish"

    def deposit(self, rupees=0, paise=0):
        if rupees < 0 or paise < 0:
            raise ValueError("Deposit must be non-negative.")
        self._balance.add(rupees, paise)
        return self._balance

    def withdraw(self, rupees=0, paise=0):
        if rupees < 0 or paise < 0:
            raise ValueError("Withdraw must be non-negative.")
        self._balance.subtract(rupees, paise)
        return self._balance

    def show_balance(self):
        return self._balance

    def __repr__(self):
        return f"BankAccount({self.account_no}, {self.customer}, balance={self._balance})"


# --- Demo (objects created from classes) ---
cust = Customer("Asha", 20, "Varanasi", "90000-00000")
acct = BankAccount(119827, cust, Money(rupees=5000, paise=0))

print(acct)
acct.deposit(rupees=250)
print("After deposit:", acct.show_balance())
acct.withdraw(rupees=100)
print("After withdraw:", acct.show_balance())

✅ Java OOP: private fields + constructor + methods

// Programmer's Picnic — OOP in Java (Champak Roy)
// Focus: encapsulation + constructor + composition

class Customer {
    private final String name;
    private final int age;
    private final String address;
    private final String phone;

    public Customer(String name, int age, String address, String phone) {
        this.name = name;
        this.age = age;
        this.address = address;
        this.phone = phone;
    }

    public String getName() { return name; }

    @Override
    public String toString() {
        return "Customer{name='" + name + "', age=" + age + ", phone='" + phone + "'}";
    }
}

class Money {
    // store in paise for accuracy
    private long paise;

    public Money(long rupees, long paise) {
        long total = rupees * 100 + paise;
        if (total < 0) throw new IllegalArgumentException("Money can't be negative.");
        this.paise = total;
    }

    public long getPaise() { return paise; }

    public void add(long rupees, long paise) {
        this.paise += rupees * 100 + paise;
    }

    public void subtract(long rupees, long paise) {
        long amt = rupees * 100 + paise;
        if (this.paise - amt < 0) throw new IllegalArgumentException("Insufficient balance.");
        this.paise -= amt;
    }

    @Override
    public String toString() {
        long r = paise / 100;
        long p = paise % 100;
        return "₹" + r + "." + (p < 10 ? "0" + p : p);
    }
}

class BankAccount {
    private final int accountNo;
    private final Customer customer; // composition
    private final Money balance;     // encapsulated field

    public BankAccount(int accountNo, Customer customer, Money openingBalance) {
        // Constructor = assembly
        this.accountNo = accountNo;
        this.customer = customer;
        this.balance = openingBalance;
    }

    public void deposit(long rupees, long paise) {
        if (rupees < 0 || paise < 0) throw new IllegalArgumentException("Deposit must be non-negative.");
        balance.add(rupees, paise);
    }

    public void withdraw(long rupees, long paise) {
        if (rupees < 0 || paise < 0) throw new IllegalArgumentException("Withdraw must be non-negative.");
        balance.subtract(rupees, paise);
    }

    public Money showBalance() { return balance; }

    @Override
    public String toString() {
        return "BankAccount{accountNo=" + accountNo + ", customer=" + customer + ", balance=" + balance + "}";
    }
}

public class Main {
    public static void main(String[] args) {
        Customer cust = new Customer("Asha", 20, "Varanasi", "90000-00000");
        BankAccount acct = new BankAccount(119827, cust, new Money(5000, 0));

        System.out.println(acct);
        acct.deposit(250, 0);
        System.out.println("After deposit: " + acct.showBalance());
        acct.withdraw(100, 0);
        System.out.println("After withdraw: " + acct.showBalance());
    }
}

✅ JavaScript OOP: class + constructor + private field

// Programmer's Picnic — OOP in JavaScript (Champak Roy)
// Focus: encapsulation (private fields) + constructor + composition

class Customer {
  constructor(name, age, address, phone) {
    this.name = name;
    this.age = age;
    this.address = address;
    this.phone = phone;
  }
  toString() {
    return `Customer(name=${this.name}, age=${this.age}, phone=${this.phone})`;
  }
}

class Money {
  constructor(rupees = 0, paise = 0) {
    const total = rupees * 100 + paise;
    if (total < 0) throw new Error("Money can't be negative.");
    this._paise = total;
  }
  add(rupees = 0, paise = 0) {
    this._paise += rupees * 100 + paise;
  }
  subtract(rupees = 0, paise = 0) {
    const amt = rupees * 100 + paise;
    if (this._paise - amt < 0) throw new Error("Insufficient balance.");
    this._paise -= amt;
  }
  toString() {
    const r = Math.floor(this._paise / 100);
    const p = this._paise % 100;
    return `₹${r}.${String(p).padStart(2, "0")}`;
  }
}

class BankAccount {
  #balance; // private field (encapsulation)
  constructor(accountNo, customer, openingBalance) {
    // Constructor = assembly of parts
    this.accountNo = accountNo;
    this.customer = customer;      // composition
    this.#balance = openingBalance;
  }
  deposit(rupees = 0, paise = 0) {
    if (rupees < 0 || paise < 0) throw new Error("Deposit must be non-negative.");
    this.#balance.add(rupees, paise);
    return this.#balance.toString();
  }
  withdraw(rupees = 0, paise = 0) {
    if (rupees < 0 || paise < 0) throw new Error("Withdraw must be non-negative.");
    this.#balance.subtract(rupees, paise);
    return this.#balance.toString();
  }
  showBalance() {
    return this.#balance.toString();
  }
  toString() {
    return `BankAccount(${this.accountNo}, ${this.customer.toString()}, balance=${this.showBalance()})`;
  }
}

// Demo
const cust = new Customer("Asha", 20, "Varanasi", "90000-00000");
const acct = new BankAccount(119827, cust, new Money(5000, 0));

console.log(acct.toString());
console.log("After deposit:", acct.deposit(250, 0));
console.log("After withdraw:", acct.withdraw(100, 0));

6) MCQ Quiz (interactive)

Attempt, submit, see explanations + score.

Score: —

7) Assignments (practice like a pro)

Do these in any language first, then port to the other two.

A1 — “Car Composition” (from Image 1)

Create classes: Engine, Wheel, Brake, Horn.
Create a Car that “has-a” Engine, 4 Wheels, Brakes, Horn.
Add methods: start(), brake(), honk().
Print a neat status report of components.

A2 — “BankAccount Rules” (from Image 2, 6)

Require minimum balance ₹500 for withdrawal.
Allow deposit only if amount > 0.
Add transaction history list (last 10 actions).
Write test cases: deposit, withdraw, edge cases.

A3 — Abstraction (from Image 5)

Create class BrakeSystem with internal steps (private/helper methods).
Expose only one public method: applyBrake().
Show that user calls one method, but many internal steps run.

A4 — Inheritance + Polymorphism

Create base class Account with deposit/withdraw.
Make SavingsAccount (interest) and CurrentAccount (overdraft rules).
Polymorphism: call withdraw() on a list of accounts and see different behavior.

Mini Project (Programmer’s Picnic ⭐)
Build a tiny console app: create customer → open account → deposit/withdraw → print statement → save statement as text.
